Unitree 4D LiDAR L2
360°×96° solid-state 4D LiDAR with photo-level scanning.
Overview
The L2 delivers 360°×96° ultra-wide non-repetitive scanning at 64,000 effective points/s with 2 cm accuracy and a 0.05 m blind spot — resisting 100 klux outdoor glare for stable indoor and outdoor mapping at a fraction of automotive-LiDAR cost.
Highlights
- 360°×96° ultra-wide non-repetitive scanning
- 64,000 points/s · 2 cm accuracy
- 0.05 m blind spot · 30 m range
- Stable under 100 klux outdoor glare
Specifications
- FOV
- 360° × 96°
- Effective frequency
- 64,000 points/s
- Range
- 30 m @ 90% reflectivity
- Accuracy
- ≤ 2.0 cm
- Weight
- 230 g · 75 × 75 × 65 mm
- Interface
- ENET UDP / TTL UART
Specifications are indicative and may vary by configuration. Contact us to confirm the exact build for your needs.
